3.2V-to-12V Power Station
with DC/DC Built-in Converter
- One Lithium Battery Cell Solution
- Auto Wide Range Voltage Charge
- Programmable 12V Output
- Economical and Portable Storage Solution
Why Unicell? The Revolutionary Single-Cell 3V to 12V converter
We integrated a high-efficiency 3V to 12V converter and MPPT solar charging into one device. Your simple, all-in-one 12V solar system is here.
Single Lithium Cell 12V Output
No volitage imbalance risk.Get stable 12V battery power supply directly from one robust LiFePO4 out NCM cell.
Built-in Solar MPPT Charge Controller
One Normal PV Panel Charge Available Wide Range MPPT Voltage Input.
Auto Charge Function
Auto-detect Charging from AC Adapter, PV, Car outlet or other 12V batteres.Can be Simulated as a Charger to Rescue Other Lithium Batteries.
High-Capacity LiFePO4 Power
User-friendly Size Compatible with 280Ah or 314Ah LFP Cells Compact 1kWh Battery storage Solution.
Detailed Display
Unicell 50 12V solar system
Unicell 100+PV 12V solar system
Specification
12V solar system
Main | ||||||
Model | Unicell 50 | Unicell 100+PV | ||||
Battery | ||||||
Battery Capacity | ~280Ah / 1kWh | |||||
Cell Chemistry | LiFePO₄ / NCM | |||||
Input | ||||||
Max. DC Input | 12/20V, 10A | |||||
PV Charging | Supported, 200W Max. | Supported, 300W Max. | ||||
Output | ||||||
Max. Discharge Current | 50A | 100A | ||||
Max. DC Output Power | 150w | 300W | ||||
DC Output Voltage | 12V-14.4V | |||||
USB Output | 2 Ports, 5V/2A | |||||
Communication | ||||||
Protocol | Modbus RS485 | |||||
Overview | ||||||
Display | Supported | |||||
Dimensions (LWH) | 15.5 x 13 x 5cm | 18 x 18 x 5cm | ||||
Application Scenarios
Drives 12V DC appliances in your RV and propels your e-kayak on the water.
Unicell Series vs. Traditional 12V Battery Banks: The Simple Choice
Feature | Traditional Series Battery Bank | Unicell 50 / Unicell 100+PV 3V to 12V converter |
System Complexity | Requires 4 batteries in series, complex wiring | Single-Cell Solution. |
Reliability | Prone to cell imbalance, single point of failure | No Series Risk. Inherently balanced and reliable |
Solar Ready | Needs expensive external MPPT controller | Built-in 3.2V MPPT Charger. Connect panels directly |
Total Cost | High (Batteries + Box + Wires + Controller) | Integrated Design. An affordable all-in-one solution |
Unicell 50 12V Power bank
Unciell 100+PV 12V Power bank
Looking for a Reliable 12V Power Solution ODM/OEM Partner?
We specialize in 12V battery power supplies, providing custom portable chargers and high-capacity storage systems. We welcome inquiries from brands and system integrators.
