500kW Liquid-Cooled Load Bank for Data Centre Commissioning
LFPWall 10K is a 51.2V 200Ah LFP battery module with the built-in BMS. It is for residential solar & storage applications and works with battery low voltage single phase or three phase hybrid inverters to achieve solar self-consumption, peak shaving or back-up supply. Battery modules can scale up by parallel connection.
- 51.2V 200Ah 10.24kWh Capacity
- Parallel connection for scale up
- Slim dimensions design
- Quick socket & plug design
- Self-addressig for multiple batteries
- IP65
- Wall mounted or ground standing
- Fire suppression module built-in
300kW Liquid-Cooled Load Bank
300kW Dual-Load Testing. Connects directly to cooling towers or CDUs to sync electrical and thermal validation in one unit. High-capacity, high-efficiency, zero IT required.
Why LCB
The only load bank that tests your power and your cooling in one operation
Simultaneous Electrical & Thermal Test
Validate power infrastructure and cooling capacity in a single commissioning run — no need for separate test equipment.
316SS Heat Exchanger
Corrosion-resistant stainless steel ensures compatibility with glycol, deionized water, and fluorinated coolants.
Wireless Cluster Control
Coordinate up to 240 units wirelessly for mega-scale commissioning — no additional controller hardware required.
Local PLC + Touchscreen HMI
Full on-site control via industrial touchscreen — no laptop required for standard commissioning sequences.
Direct Cooling Tower Connection
Pipe directly into your facility cooling loop — eliminates the need for separate heat dissipation infrastructure on site.
Technical Specifications
Select a model to view its detailed parameters
| Parameter | Value |
|---|---|
| Rated Power | 100 kW |
| Load Type | Resistive, 1% step |
| Rated Voltage | 400 V AC 3-phase 4-wire |
| Frequency | 50 / 60 Hz (optional) |
| Power Factor / THD | PF > 0.99 | THD < 3% |
| Cooling Method | Liquid-cooled (L–L heat exchange) |
| Heat Exchanger | 316 stainless steel |
| Thermal Output | 100 kW |
| Temperature Accuracy | ±0.5 °C |
| Cooling Interface | DN100 / DN50 |
| Coolant Compatibility | Glycol / deionized water / fluorinated coolant |
| Control Interface | TCP/IP + Modbus RTU + HMI touchscreen |
| Paralleling | Up to 240 units (24 MW) |
| Protection Rating | IP54 / IP55 (optional) |
| Operating Temperature | 0 °C – 45 °C |
| Certifications | IEC 60947-1, IEC 60947-4-1, CE (standard) / UL (optional) |
| Installation | Floor-standing (casters / trailer) |
| Special Features | Direct Cooling Tower connection, Wireless Cluster |
Applications
Where the LCB series delivers proven results
Data Center Electrical Commissioning
Full-load acceptance testing of HV/MV switchgear, UPS, and PDU at up to 500 kW per unit — with real thermal load rather than dummy resistors.
CDU & Chiller Performance Testing
Verify cooling distribution unit capacity, chiller sequencing, and cooling tower efficiency under design load conditions before IT equipment arrives.
Thermal Chain Validation
Trace heat rejection from servers through CDU, cooling tower, and chiller to identify bottlenecks and prove PUE targets before go-live.
Certifications
Compliance you can count on
CE Marked
Standard
IEC 60947-1
International Standard
IEC 60947-4-1
AC Contactors & Starters
UL Listed
Optional
Wireless Cluster — Up to 240 Units
Deploy multiple LCB units in a coordinated wireless cluster for mega-watt commissioning projects. A single operator controls the entire fleet via TCP/IP — scaling from 100 kW to 84 MW+ without additional hardware. Each unit retains its local HMI for autonomous fallback operation.
